Cheatsheets

GitHub Actions

The workflow YAML you write over and over. Triggers, jobs and steps, secrets, matrix builds, caching, artifacts, and reusable workflows in one reference.

6 Categories11 Sections14 ExamplesPublished: 04 Aug, 2026Updated: 04 Aug, 2026
GitHub ActionsworkflowCI/CDmatrix buildsecretscachingreusable workflowcomposite action

GitHub Actions runs your CI/CD directly from YAML files in .github/workflows/, and most of the job is knowing which key does what. A workflow reacts to events, splits into jobs that run on runners, and each job is an ordered list of steps that either call a reusable action or run a shell command.

This cheatsheet walks the parts you touch on every pipeline: triggers that decide when things run, the job and step structure, env and secrets across their three scopes, matrix builds for testing many versions at once, caching and artifacts to stay fast, and reusable workflows and composite actions to stop copy-pasting the same YAML into every repo.

Key Features

  • Trigger precisely: filter push and pull_request by branch and path, plus schedule and workflow_dispatch.
  • Structure jobs: needs for ordering, if for conditions, runs-on for the machine.
  • Handle secrets safely: three env scopes, masked secrets, and a least-privilege GITHUB_TOKEN.
  • Scale and reuse: matrix builds, dependency caching, artifacts, reusable workflows, and composite actions.

Workflow Triggers

The on key decides when a workflow runs. Most workflows use one or two of these, but knowing the full set saves you from cron hacks and manual reruns.

Event Triggers

Fire on repository activity like pushes and pull requests, and filter down to the branches, tags, and paths you actually care about.

Trigger on push and pull request with filters

paths and paths-ignore skip runs that can't matter, which keeps queues short and saves runner minutes on docs commits.

Code
on:
# Run on pushes to main, but only when source or workflows change
push:
branches: [main]
paths:
- 'src/**'
- '.github/workflows/**'
# Run on PRs targeting main, ignoring docs-only changes
pull_request:
branches: [main]
paths-ignore:
- '**.md'
  • Use branches-ignore or paths-ignore for the inverse of branches/paths. Don't set both the positive and negative form for the same key.
  • Tag pushes need a tags filter (for example, tags:['v*']). A branches filter alone never matches a tag push.

Scheduled and manual triggers

workflow_dispatch gives you a manual run button plus typed inputs, and schedule runs on cron without any external trigger.

Code
on:
# Cron runs in UTC. This is 02:00 UTC every day.
schedule:
- cron: '0 2 * * *'
# A "Run workflow" button in the Actions tab, with inputs
workflow_dispatch:
inputs:
environment:
description: 'Target environment'
type: choice
options: [staging, production]
default: staging
  • Scheduled workflows only run from the default branch, and GitHub can delay or skip them under heavy load. Don't rely on exact timing.
  • Reach an input at runtime with ${{ inputs.environment }} (or github.event.inputs.environment on older syntax).

workflow_call and Reuse

workflow_call turns a workflow into something other workflows can invoke, which is the foundation of reusable pipelines.

Expose a workflow as callable

A workflow with on:workflow_call declares typed inputs and named secrets, so callers pass exactly what it needs and nothing more.

Code
on:
workflow_call:
inputs:
node-version:
required: false
type: string
default: '20'
secrets:
npm-token:
required: true
  • Reusable-workflow inputs are typed (string, number, boolean). This is stricter than workflow_dispatch, which historically treated everything as a string.

Jobs and Steps

Jobs run on runners and can depend on each other. Steps run in order inside a job, either calling an action with uses or running a shell command with run.

Job Structure

runs-on picks the machine, needs builds a dependency graph, and if gates whether a job runs at all.

Chain jobs with needs and conditions

needs makes deploy wait for build to succeed, and the if guard stops deploys from running on pull requests or feature branches.

Code
jobs:
build:
runs-on: ubuntu-latest
steps:
- run: echo "building"
deploy:
# Wait for build, and only deploy from main
needs: build
if: github.ref == 'refs/heads/main'
runs-on: ubuntu-latest
environment: production
steps:
- run: echo "deploying"
  • By default a needed job must succeed. Use if:always() or if:needs.build.result == 'success' to control behaviour when an upstream job fails.
  • [object Object]

Run a job across multiple OSes

Setting runs-on to a matrix value fans the same job out across every listed OS in parallel.

Code
jobs:
test:
runs-on: ${{ matrix.os }}
strategy:
matrix:
os: [ubuntu-latest, macos-latest, windows-latest]
steps:
- uses: actions/checkout@v4
- run: echo "testing on ${{ matrix.os }}"

Steps, uses, and run

Every step either reuses a published action (uses) or runs shell commands (run). with passes inputs, env sets variables.

Combine actions and shell steps

uses pulls in a reusable action and with feeds it inputs, while run executes shell directly. The | starts a multi-line script block.

Code
steps:
# An action from the marketplace, pinned to a major version
- uses: actions/checkout@v4
- uses: actions/setup-node@v4
with:
node-version: '20'
cache: 'npm'
# A multi-line shell command with a step id and env
- name: Build
id: build
env:
NODE_ENV: production
run: |
npm ci
npm run build
  • Give a step an id when a later step needs its outputs via ${{ steps.build.outputs.name }}.
  • Default shell is bash on Linux/macOS and pwsh on Windows. Override per step with shell:bash for consistency.

Variables and Secrets

env holds plain configuration at three scopes, while secrets and the GITHUB_TOKEN handle anything sensitive without ever printing it in logs.

Environment Variables

Set env at the workflow, job, or step level. The narrowest scope wins when the same name is defined twice.

env at three levels and dynamic values

A step-level env wins over job-level, which wins over workflow-level. To pass a computed value forward, append it to the $GITHUB_ENV file.

Code
env:
APP_NAME: my-app # available to every job and step
jobs:
build:
runs-on: ubuntu-latest
env:
LOG_LEVEL: debug # available to every step in this job
steps:
- name: One-off value
env:
STAGE: build # only this step
run: echo "$APP_NAME $LOG_LEVEL $STAGE"
- name: Export to later steps
# Writing to $GITHUB_ENV persists a var to the next steps
run: echo "VERSION=1.2.3" >> "$GITHUB_ENV"
  • Read repository or environment configuration variables (non-secret) with ${{ vars.NAME }}, distinct from ${{ secrets.NAME }}.

Secrets and GITHUB_TOKEN

Secrets are encrypted, masked in logs, and injected only where you reference them. Every run also gets a scoped GITHUB_TOKEN for free.

Use secrets and pass them to a reusable workflow

Reference a secret with ${{ secrets.NAME }}, and forward secrets to a called workflow explicitly or with secrets:inherit.

Code
jobs:
publish:
runs-on: ubuntu-latest
steps:
- env:
NPM_TOKEN: ${{ secrets.NPM_TOKEN }}
run: npm publish
call-shared:
uses: ./.github/workflows/deploy.yml
# Forward a named secret to the reusable workflow
secrets:
npm-token: ${{ secrets.NPM_TOKEN }}
# Or hand over everything the caller has:
# secrets: inherit
  • GitHub masks secret values in logs automatically, but a secret you echo after transforming (base64, for example) can leak. Don't print them.
  • Prefer OIDC (id-token:write plus a cloud role) over long-lived cloud keys stored as secrets.

Least-privilege GITHUB_TOKEN

Set a restrictive top-level permissions block, then widen it per job. The auto-generated GITHUB_TOKEN inherits exactly those scopes.

Code
# Default to read-only for the whole workflow
permissions:
contents: read
jobs:
release:
runs-on: ubuntu-latest
# Grant just what this job needs
permissions:
contents: write
packages: write
steps:
- run: gh release create v1.0.0
env:
GH_TOKEN: ${{ secrets.GITHUB_TOKEN }}
  • Secrets are not passed to workflows triggered by pull_request from a fork, which is a deliberate safeguard against untrusted PRs.

Matrix Builds

A matrix runs the same job across a grid of parameters (versions, OSes) in parallel, with include and exclude to fine-tune the combinations.

strategy.matrix

List the axes and GitHub generates one job per combination. include adds extra entries, exclude removes specific ones.

Multi-axis matrix with include and exclude

The two axes create 6 jobs, exclude removes one, and include appends a tailored entry, so you end up with a precise test grid.

Code
strategy:
# Keep other jobs running if one combo fails
fail-fast: false
# Cap parallel jobs so you don't exhaust runners
max-parallel: 4
matrix:
node: [18, 20, 22]
os: [ubuntu-latest, windows-latest]
# Drop a combo that isn't supported
exclude:
- node: 18
os: windows-latest
# Add an extra one-off combo with a custom flag
include:
- node: 22
os: ubuntu-latest
experimental: true
  • fail-fast:true (the default) cancels every other matrix job the moment one fails. Set it false when you want the full result grid.
  • Reference any axis value in the job with ${{ matrix.node }} or ${{ matrix.os }}.

Caching and Artifacts

Caching reuses dependencies between runs to save time. Artifacts pass build outputs between jobs or hand them to you after the run.

Dependency Caching

actions/cache keys a directory by a hash of your lockfile, restoring it when the hash matches and saving a fresh copy when it doesn't.

Cache dependencies keyed by lockfile

A cache hit restores ~/.npm instantly. On a miss, restore-keys grabs the newest partial match and the run saves a new cache under the exact key.

Code
- uses: actions/cache@v4
with:
path: ~/.npm
# Exact key: changes when the lockfile changes
key: ${{ runner.os }}-npm-${{ hashFiles('**/package-lock.json') }}
# Fallback prefixes for a partial (warm) restore
restore-keys: |
${{ runner.os }}-npm-
  • Many setup actions have caching built in (setup-node with cache:'npm'). Prefer that over a manual actions/cache step when it exists.
  • Caches are scoped to a branch and its base. A PR can read the base branch cache but a branch can't read an unrelated branch's cache.

Build Artifacts

Upload files from one job and download them in another, or keep them attached to the run for later inspection.

Pass a build between jobs

upload-artifact stores dist/ from the build job, and download-artifact pulls it into the deploy job by matching the artifact name.

Code
jobs:
build:
runs-on: ubuntu-latest
steps:
- run: npm run build
- uses: actions/upload-artifact@v4
with:
name: dist
path: dist/
retention-days: 7
deploy:
needs: build
runs-on: ubuntu-latest
steps:
- uses: actions/download-artifact@v4
with:
name: dist
path: dist/
- run: ls dist/
  • Artifacts are not caches. Use artifacts to move files between jobs or keep outputs, and use actions/cache to speed up dependency installs.
  • v4 of the artifact actions is not cross-compatible with v3. Keep upload and download on the same major version.

Reuse and Composition

Kill the copy-paste. Reusable workflows share a whole pipeline across repos, and composite actions bundle a sequence of steps into one uses call.

Reusable Workflows

Call an entire workflow from another with uses, passing inputs and secrets. Great for standardizing deploys across many repos.

Call a reusable workflow

A job that sets uses to a workflow file calls it wholesale, forwarding typed inputs and either named secrets or secrets:inherit.

Code
jobs:
deploy:
# Local reusable workflow
uses: ./.github/workflows/deploy.yml
with:
node-version: '20'
secrets:
npm-token: ${{ secrets.NPM_TOKEN }}
deploy-shared:
# Reusable workflow from another repo, pinned to a tag
uses: my-org/ci-workflows/.github/workflows/deploy.yml@v2
secrets: inherit
  • A caller can nest reusable workflows up to 4 levels deep. Beyond that GitHub refuses to run the chain.
  • Pin cross-repo reusable workflows to a tag or SHA, never a moving branch, so a change upstream can't silently alter your pipeline.

Composite Actions

Bundle several steps into a single action defined by an action.yml, then call it like any marketplace action.

Define a composite action

runs.using:composite lets one action.yml wrap multiple steps, so callers replace a repeated block with a single uses:./.github/actions/setup.

Code
.github/actions/setup/action.yml
name: 'Setup project'
description: 'Checkout, install Node, and restore deps'
inputs:
node-version:
default: '20'
runs:
using: composite
steps:
- uses: actions/setup-node@v4
with:
node-version: ${{ inputs.node-version }}
# Composite run steps MUST declare a shell
- run: npm ci
shell: bash
  • Every run step inside a composite action must set shell explicitly. Omitting it is the most common composite-action error.
